| PART |
Description |
Maker |
| PI74STX1GT86CX PI74STEX1GT86CEX PI74STX1GT86TX PI7 |
STX SERIES, 2-INPUT XOR GATE, PDSO5 SC-70, 5 PIN
STEX SERIES, 2-INPUT XOR GATE, PDSO5 SC-70, 5 PIN
STX SERIES, 2-INPUT XOR GATE, PDSO5 SOT-23, 5 PIN
STEX SERIES, 2-INPUT XOR GATE, PDSO5 SOT-23, 5 PIN
|
Pericom Semiconductor, Corp.
|
| HEC4002BT HEC4002BT112 |
Dual 4-input NOR gate; Package: SOT108-1 (SO14); Container: Tube 4000/14000/40000 SERIES, DUAL 4-INPUT NOR GATE, PDSO14
HEF4002B gates; Dual 4-input NOR gate
|
NXP Semiconductors N.V.
Philips
|
| MC10109 MC10109FN MC10109L MC10109P ON0555 |
Replaced by SN54LS132 : Quadruple 2-Input Positive-NAND Schmitt Triggers 14-CDIP -55 to 125 10K SERIES, DUAL 5-INPUT OR/NOR GATE, PQCC20
Dual 4-5-Input OR/NOR Gate
PIN ASSIGNMENT
From old datasheet system
|
Motorola Mobility Holdings, Inc.
Motorola, Inc
ONSEMI[ON Semiconductor]
|
| 74ABT20D-T 74ABT20DB118 |
Dual 4-input NAND gate - Description: Dual 4-Input NAND Gate ; Logic switching levels: TTL ; Number of pins: 14 ; Output drive capability: -15/ 20 mA ; Propagation delay: 2.7 ns; Voltage: 4.5-5.5 V ABT SERIES, DUAL 4-INPUT NAND GATE, PDSO14
|
Ecliptek, Corp.
NXP SEMICONDUCTORS
|
| 74LVC2G32DP125 74LVC2G32DC125 |
Dual 2-input OR gate, SOT505-2 (TSSOP8), Reel Pack, Reverse LVC/LCX/Z SERIES, DUAL 2-INPUT OR GATE, PDSO8
Dual 2-input OR gate, SOT765-1 (VSSOP8), Reel Pack, Reverse LVC/LCX/Z SERIES, DUAL 2-INPUT OR GATE, PDSO8
|
NXP Semiconductors N.V.
|
| 74LVC2G86GT115 |
Dual 2-input EXCLUSIVE-OR gate; Package: SOT833-1 (XSON8U); Container: Reel Pack, SMD, 7" LVC/LCX/Z SERIES, DUAL 2-INPUT XOR GATE, PDSO8
|
NXP Semiconductors N.V.
|
| MC10H21106 MC10H211FNG MC10H211FNR2 MC10H211FNR2G |
Dual 3-Input 3-Output NOR Gate; Package: 20 LEAD PLLC; No of Pins: 20; Container: Rail; Qty per Container: 46 10H SERIES, DUAL 3-INPUT NOR GATE, PQCC20
Dual 3−Input 3−Output NOR Gate
|
ONSEMI[ON Semiconductor]
|
| MC74HC58 ON1484 MC74HC58D |
2-Wide, 2-Input/2-Wide, 3-Input AND-OR Gates HC/UH SERIES, DUAL 6-INPUT AND-OR GATE, PDSO14
From old datasheet system
|
Motorola Mobility Holdings, Inc.
ON Semi
|
| 74AUP2G08DC125 74AUP2G08GD125 |
Low-power dual 2-input AND gate; Package: SOT765-1 (VSSOP8); Container: Reel Pack, Reverse, Reverse AUP/ULP/V SERIES, DUAL 2-INPUT AND GATE, PDSO8
Low-power dual 2-input AND gate; Package: SOT996-2 (XSON8U); Container: Reel Pack, Reverse, Reverse AUP/ULP/V SERIES, DUAL 2-INPUT AND GATE, PDSO8
|
NXP Semiconductors N.V.
|
| 74LVC2G00GF 74LVC2G00GD 74LVC2G00DP |
Dual 2-input NAND gate LVC/LCX/Z SERIES, DUAL 2-INPUT NAND GATE, PDSO8
Dual 2-input NAND gate 输入与非
|
NXP Semiconductors N.V.
|
| NL27WZ0006 NL27WZ00USG |
Dual 2−Input NAND Gate 27WZ SERIES, DUAL 2-INPUT NAND GATE, PDSO8
|
ON Semiconductor
|
