| PART |
Description |
Maker |
| 2301 |
2.3 GHz Class C, Common Base; fO (MHz): 0; P(out) (W): 1.5; P(in) (W): 0.24; Gain (dB): 8.5; Vcc (V): 20; Cob (pF): 4; Case Style: 55BT-1 S BAND, Si, NPN, RF SMALL SIGNAL TRANSISTOR
1.5 Watt - 20 Volts, Class C Microwave 2300 MHz
|
MICROSEMI POWER PRODUCTS GROUP
Microsemi, Corp.
GHZTECH[GHz Technology]
GHz Technology, Inc.
|
| 0912-7 0912-7-3 0912-7-2 |
From old datasheet system
Intemally Matched, Common Base Transistor
7 W, 50 V internally matched, common base transistor
|
List of Unclassifed Manufacturers
ETC[ETC]
Electronic Theatre Controls, Inc.
Acrian
|
| MRF517 |
Small Signal, Up to 1 GHz, Class A, Common Emitter; fO (MHz): 0; fT (MHz): 3000; GNF (dB): 10; VCE (V): 15; IC (mA): 60; NF min (dB): 2.5; Case Style: TO-39 UHF BAND, Si, NPN, RF POWER TRANSISTOR, TO-39
|
Microsemi, Corp.
|
| 2324-12L |
12 W, 20 V, 2300-2400 MHz common base transistor
12 Watts - 20 Volts, Class C Microwave 2300 - 2400 MHz
NV Trimmer Potentiometer
|
GHz Technology
|
| 1719-20 |
20 W, 28 V, 1700-1900 MHz common base transistor
20 Watt - 28 Volts, Class C Microwave 1700 - 1900 MHz
BJT
|
GHZTECH[GHz Technology]
|
| MDS800 |
RF Power Transistors: AVIONICS
MODE-S, 1030/1090 MHz, Class C, Common Base, Pulsed ; P(out) (W): 800; P(in) (W): 110; Gain (dB): 8.5; Vcc (V): 50; Pulse Width (µsec): 128; Duty Cycle (%): 2; Case Style: 55ST-1 L BAND, Si, NPN, RF POWER TRANSISTOR
|
Advanced Power Technology
Microsemi, Corp.
|
| 1415-7 |
7 W, 20 V, 1430-1540 MHz common base transistor
|
GHz Technology
|
| TCS800 |
high power COMMON BASE bipolar transistor.
|
ADPOW[Advanced Power Technology]
|
| SD1495-3 |
RF & MICROWAVE TRANSISTORS 900-960 MHz CLASS C BASE STATIONS
|
Microsemi Corporation
|
| UMIL60 |
60 Watts, 28 Volts, Class AB Defcom 225 - 400 MHz
UHF 225-400 MHz, Class C, Common Emitter; P(out) (W): 60; P(in) (W): 8; Gain (dB): 0; Vcc (V): 28; Cob (pF): 70; fO (MHz): 0; Case Style: 55HW-2 UHF BAND, Si, NPN, RF POWER TRANSISTOR
|
Microsemi Corporation
Vishay Semiconductors
|
| 1719-8 |
8 W, 28 V, 1700-1900 MHz common base transistor
BJT
|
GHz Technology
|
|
